Hob built-in Mood 110 Cm Glass Ceramic Black images
Barazza Mood 1PMD104N — Mood 110 cm built-in gas hob; black glass ceramic (4 mm), cast-iron pan supports. Flat Eco-Design: 4 burners, overall dimensions 1100 × 400 mm, cut-out 1070 × 370 mm.
The Mood 110 cm model measures 1100 × 400 mm overall and needs a 1070 × 370 mm cut-out. Barazza Mood 1PMD104N combines Flat Eco-Design gas burners with cast-iron pan supports. Its double-ring burner delivers 4 kW. Surface: black glass ceramic, 4 mm.
Barazza describes the vertical flame of its Flat Eco-Design burners as designed for efficient, even heat distribution. Burner outputs: 1 auxiliary 1 kW; 1 semi-rapid 1.75 kW; 1 rapid 3 kW; 1 double ring 4 kW.
Overall size (W × D): 1100 × 400 mm. Cut-out (W × D): 1070 × 370 mm. Check the official technical drawing before cutting the worktop, and select the gas variant suited to the installation.
Download the official Barazza drawing from the Download section.
Barazza Mood 1PMD104N is the specific 110 cm model with 4 gas burners. Its overall dimensions are 1100 × 400 mm, while the worktop cut-out is 1070 × 370 mm. These measurements serve different purposes: the hob occupies more space on the surface than the opening beneath it. Check both against your kitchen plan before ordering, especially when replacing an existing appliance.
Check the selected gas variant and the connections available in your kitchen as well. Dimensions alone do not confirm that an existing worktop can be reused. The manufacturer drawing shows where gas and electrical connections sit. Barazza specifies cast-iron pan supports and a 4 kW double-ring burner for this model. Compare the surface finish with other kitchen materials, then compare the available widths and finishes in the Mood range.
Use the official technical drawing for final planning. It identifies the exact model and its installation dimensions. Follow the manufacturer instructions during fitting and have the gas connection handled according to local requirements.
