Induction charger images
Kitchen accessories Barazza
Barazza 1CBI is a built-in induction charger with a satin steel finish, 10 W maximum power and a 60 mm cut-out.
Description
Barazza 1CBI is an induction charger designed for installation in a kitchen worktop. Its visible surface has a satin stainless steel finish.
Barazza lists fast charging support and 79% charging efficiency. The functions include an LED indicator, selective device detection and safety switch-off. Input is 110–240 V AC at 50/60 Hz. Output is 5 V or 9 V at 1.1 A, with a maximum power of 10 W. Check the device to be charged against these electrical specifications.
The external diameter is 68 mm and the worktop cut-out diameter is 60 mm. The official technical drawing allows installation only in tops from 5 mm minimum to 32 mm maximum thickness. Check both the opening and top thickness before cutting, and use the official drawing for installation. The PDF states a gross weight of 0.8 kg.
Technical details
Official technical drawing and installation dimensions for the induction charger.
